A collection of engineering graphics. Fazlulin E.M.

A textbook was created in accordance with the Federal State Educational Standard for Technical areas of training (qualification "bachelor").

contains questions for self -training, exercises for them (most with answers) on the main sections of the course "Engineering graphic arts". It helps to study the basic provisions of the rules for the implementation of drawings, the features of the image of some machine -building parts and their compounds, acquire skills of drawing up and reading drawings of parts, assembly drawings, general types and specifications for them.

for students of higher professional education institutions.
