ABC of radio electronics. Koldunov A.S.

This is a tutorial for those who want to learn how to understand the radio electronics. You will receive information about what the radio electronics are, what the devices consist of, what is included in the concept of the element base and what functions various elements perform, acquire skills in working with schemes.

The first volume is dedicated to the basics of digital technology. It discusses the principles of work and features of the application of modern logical microcircuits. Examples of practical structures on microcircuits are given.

The analog technique is presented in the second volume, which describes amplifier devices, electronic lamps, transistor amplifiers.

readers will get acquainted with the circuitry and the rules for the coordination of digital and analog schemes , a description of power sources, calculations of elements and transformers, will learn how to work with measuring devices, mounting tools, get acquainted with the skills of manufacturing fees.

Currently, components of foreign production are more accessible than domestic ones. In this regard, for the convenience of readers, in addition to the available materials at the end of the “Appendix” section, foreign analogues of most domestic components that are found in both volumes of the book are given. The book is designed for schoolchildren and beginner radio amateurs.
