Block-modular SAPR of galvanic lines. Tutorial. Sokolov M.V.

A literary and patent overview of the current state of automated design systems has been carried out. The functions, procedures and structure of the block-modular CAD of galvanic lines are determined. The choice of software for the development of CAD blocks was made. The software has been developed that allows you to calculate the technological and constructive parameters of galvanic equipment. The constructive and regime parameters of galvanic lines are determined, subject to optimization. As an optimization criterion, the minimum costs of the process of applying the coating process are selected. The task of optimizing the process of applying the coating was performed.

For senior students and undergraduates in the areas of undergraduate on 03/15/05, 03/15/01 and magistrates 04/15/05, 04/15/01 "Design and technological support for machine-building industries", profile "Mechanical Engineering Technology" and "Mechanical Engineering" , profile "Digital engineering", respectively.
