Car Antenna "Triad-150 Gold", active, interchangeable, two modes

Active triad-150 Gold antenna is designed for a high-quality radio in the city and on the highway. It differs from the "triad-100" by the presence of an amplifier switch. This function is useful in a city where, near radio racks and cellular towers, the strengthening is necessary. Outside the city, the inclusion of a turbo-mode will allow you to enjoy the quality reception of radio waves for a long time.

Installation:

• The antenna consists of a round plastic case, from which thin metallized reception canvases are emerged. LI>
• Antenna is installed in the angle of the windshield or under the rear view mirror, the case is glued to bilateral tape to the glass.
• The canvases are glued along the lobe of the windshield.
• The antenna consumes electric current and it requires a power supply of 12 volts from the on -board network of the car.
• The indicator of the correct connection is the LED.

the antenna case is made of black plastic (in the form of a thick disk radius near 4.5 cm and 1.8 cm thick), which is glued to the right passenger angle of the windshield to a bilateral black tape. Sometimes such antennas are popularly called the "tablet". Thin metallized self -adhesive reception canvases (mustache) come out of the case, which are also glued to glass. The receiving mustache can be expanded at any angle so that the antenna on the glass can be installed both in the glass angle and in the center under the rear view mirror. The antenna case consists of two parts. When installing, the first part of the housing is first glued to the selected place, the mustaches are put on the pin of this part, glued to the glass and the second part of the case with wires is filled on top. The pipelines are removed to the edge of the glass and laid under a sealing gum or plastic part of the body adjacent to the windshield.
