Design in T-Flex CAD in tasks and examples. 131 Task for independent development. Tulpinova N.V.

The book is a textbook for students of technical directions of universities and colleges, as well as students of industrial centers of competencies and quantorium pupils, but will also be useful to engineers who decided to move on to use T-Flex CAD from other design systems. The first part of the book is devoted to two-dimensional digital modeling in T-Flex CAD and is aimed at the formation of confident practical skills necessary for the subsequent transition to 3D. The second part is dedicated to three-dimensional digital modeling in T-Flex CAD and is aimed at forming practical skills in the design of digital models of mechanical engineering products. After considering each example of constructing a drawing, details or assembly, the reader offers a wide range of options presented in the chapter such as digital models in the form of tasks for independent development.

for engineers and students of technical universities and colleges
