Digital circuitry. From the basics to the creation of practical devices. Shustov M.A.

The materials of an interactive self -appaid will allow the reader to go from the development of the basics of the elements and nodes of digital electronics to the heights of professional skill in circuitry. The text of the book contains QR codes intended for an instant transition to the necessary resources (video, reference information) illustrating the material under consideration.

The basics of digital technology, the principles of construction and the work of the basic elements of digital electronics, from simple to it Complex. Examples of practical solutions to the construction of individual nodes and working fragments of real schematic solutions are shown.

The main part of the book describes the creation of practical devices that are useful in everyday life. A collection of fairly simple schemes of various digital devices available for self -repetition is given. Then hundreds of examples of use of digital chips in various technical devices, measuring equipment, radio communications, medical and household appliances are given.

The book is intended for a wide range of readers. It can simultaneously be useful both to beginner radio amateurs, participants in the mugs of technical creativity, students of technical schools, universities, and engineers sophisticated in digital schematics.
