Digital circuitry. Fundamentals of construction. Shustov M.A.

Digital devices confidently entered the life of every modern person with means of communication, information processing devices, television equipment, modems, routers and many others. During the dialogue, the author of the book and the beginner go from the basics to the heights of skill, from the study of elementary construction elements of digital equipment to the creation of independent practical constructions. The book is simple in perception and is easy to read.

at the first stage, the beginner considers the basic elements of digital technology, their construction. Then he gets acquainted with the stages of development of digital circuitry. The second chapter provides useful reference information on the features of digital microcircuits, without which their use will be difficult. The third chapter discusses the principles of construction and the work of basic elements of digital equipment, from simple to complex. Examples of practical solutions to the construction of individual nodes and working fragments of real schematic solutions are shown.

in the final chapter, the author and an advanced beginner proceed to the creation of practical devices that are useful in everyday life. The collection of fairly simple schemes of various digital devices is given, available for independent repetition by a novice radio amateur.

The book is intended for a wide range of readers. It can simultaneously be useful to both the beginner and the user sophisticated in digital schematic.
