Digital circuitry. Practice of application. Shustov M.A.

The book proposed to the attention of the reader is universal in content and consists of two interconnected parts. In the first of them, the reader will get acquainted with the basics of modeling digital devices using the NI Multisim schematic modeling program popular in our country and abroad. In the second part of the book, an encyclopedically complete collection of electronic circuits of various functional purposes is presented, made using digital microcircuits. Examples of use of digital microcircuits in analogue devices, options for diagrams of various generators on digital chips, the use of digital chips in measuring equipment, in the technique of radio communications, medical and household appliances.

these electronic circuits, despite its simplicity, in They are fully responding to their purpose and, in addition, are most accessible for self -repetition both in the “hardware” and in terms of studying the principle of their work using a package of schematic modeling programs NI Multisim.

Detailed the applications. Reference data on elements of digital technology: the composition of the series of TTL and CMOP-microchm, their purpose and approximate analogues, as well as basement.

The book is intended for a wide range of modern radio amateurs and students of radio universities and technical schools.
