Fundamentals of computer modeling of electronic systems and signals. Tutorial. Rubtsov E.A., Kudryakov S.A.

The description of the working environment of the Multisim program, the MatLab application package, the Simulink modeling application. The process of generating and visualizing the simplest determinated signals, decomposition of the analog signal and the use of a Fourier series is presented. The generation and visualization of signals with amplitude and angular modulation, sampling of continuous signals, generation and visualization of noise signals are described. The gear function of the four -pole, the frequency and temporal characteristics of electric circuits, passive and active electrical filters, and the generation of autocolnia are investigated. Digital filters are studied, a general acquaintance with the working environment of Mmana Gal modeling is made. Examples of modeling radio electronic systems and signals, as well as antennas of radio engineering systems of civil aviation.

for students studying in the specialty program in the specialty 05/25/05 “Operation of aircraft and the organization of air traffic”, specialization “Organization of radio support for radio support aircraft flights ”, for students studying in the undergraduate and magistracy program in the direction of 03.03.04“ Operation of airports and providing aircraft flights ”and direction on 03/25/03“ Aeronavigation ”, as well as for students students under the program of secondary special education in the specialty 02/25/08 "Operation of unmanned aviation systems".
