Methodology for modeling the dynamics of steam turbine installation TK-38/38-3.4 based on HS. Korsakov Alexander Romanovich, Shchekaturov Alexander Mikhailovich

The book examines in detail the creation of a turbine model based on the HS heat-gydraulic code-the Simlntech dynamic modeling module. This process is shown in the example of modeling the dynamics of one of the small steam turbines (vocational schools). A step -by -step description of the development of a model of the sensor, executive mechanism and regulators for a comprehensive model is also given on the example of level regulators in heaters, in the deaerator and in the main capacitor. Despite the fact that the emphasis in the method is made on a specific turbine, the book will be useful to everyone who wants to independently develop a dynamic model for another steam turbine installation, gas turbine, turbine unit or thermophysical facility.
