Schemics of digital devices. Theory and practice. Textbook. Galochkin V.A.

The elemental base and circuitry of digital devices is considered: logical elements, triggers, meters, encryptions, decoders, multiplexers, demultiplexors, ADP and DAC devices. The theoretical principles of schematic solutions, the rules and patterns of the functioning of devices of digital technology for each topic (theory) are accompanied by an experimental verification of the rules and the features of their functioning (practice). The check is carried out both in manual and dynamic modes. Recommendations are given on conducting experiments and the design of their results.

for organizing educational or independent work of students of day and correspondence forms of training, as well as for engineering and technical workers studying electronics.
