Three -axle electronic Greenbean Istab Smart

Any mobile phone will become a professional camera if you use the GreenBean Istab Smart stabilizer. With it, even a regular phone will be able to create smooth high -quality videos. The design of the integrated control panel is designed in this way that it allows you to control the stabilizer and mobile chamber using buttons, practically without using the touch screen.

Thanks to advanced software, it correctly processes such “complex” positions for electronic stacks as a tilt of the handle by 45 degrees, or the location of two engines close to alignment. And due to the use of high -quality and accurately made bearings, you will be spared from problems with vibrations, buzzing, various noises and other defects inherent in many simpler models.

The stabilizer case is made of aluminum alloy, there is a notch for better holding on the handle. The device comes from one battery of type 18650 Battery charging is carried out through the micro-USB port on the device housing. Continuous work time is 5 hours (with a 2600 mAh battery with a capacity of 2600).

The stabilizer connects to the Bluetooth smartphone. The smartphone camera is controlled by one button and a five -position joystick.

In the holder, you can install a smartphone with a width of 60 to 85 mm. For models with a large screen, it is necessary to install a complete cargo-fingers to prevent the tilt of the smartphone to the left. On the stabilizer handle there is a hole with a 1/4 ″ thread for installation on a tripod or appropriate selfie-stick. For installation on an action camera stabilizer, an adapter is required (it is purchased separately).

Stabilizer operating modes

• Stabilization with panoraming (single pressing). The smartphone/action camera smoothly follows the turns of the handle, preserving the vertical and horizontal orientation of the screen, the axis of the inclination and rotation are fixed.
• Stabilization with panoraming and tilt (double pressing). The smartphone smoothly repeats the turns and inclinations of the handle, preserving the horizontal orientation of the screen, the axis of rotation is fixed.
• complete stabilization in the current position (three -fold pressing). All the axes of the stabilizer are fixed with any movement of the operator, the orientation of the plane of the screen of the smartphone is preserved.
• transfer of the camera to a vertical position and vice versa (four -fold pressing). The smartphone is transferred to a vertical position, after which it follows smoothly beyond the bending of the handle, maintaining the orientation of the screen in the vertical plane, the axis of the inclination and rotation are fixed.
• Turning on/off the occasion of the camera from the joystick (long press, more than 3 seconds)

Calibration of the stabilizer

The stabilizer calibration can be carried out both automatically and using software by connecting your stabilizer to a computer via a USB port.

Features of the electronic stabilizer

Using software installed on a smartphone, can be monitored by an object or person/persons with a simple choice of tracking area on the screen, automatic photography of the panoramas of 180/360, just wide -angle shots or shooting of vertical video for short shorts or stories in social networks. Also, with its help, you can control such settings as compensation for the exposure, installation of ISO, correction of white balance, change the ratio of the side of the frame, control the flash, choose a front or rear camera for shooting. One of the interesting features of this software is the possibility of shooting time laps (accelerated video). It is possible to speed up the video from 3 to 120 times.
