Microwave devices and antennas. Part 1. Design, constructive implementation, examples of the application of microwave. Neganov V.A., Klyuyev D.S., Tabakov D.P.

The first part of this textbook discusses the methods of designing and constructive implementation of microwave devices: transmission lines of various types, resonators, filters, phaseuristers, attenuers, trigeminal joints, directed branches, various bridge joints, ferrite devices (valves, circulators, phase revolbs) and Microwave devices on semiconductor diodes. Examples of the use of microwave devices in radio communications, radar, in measuring equipment, etc.

In the second part, the main sections of the theory and technology of antennas are given. The issues of calculating and constructing various types of antennas (from vibrator to shutter and antenna gratings, including phased) are highlighted. The main attention is paid to the antennas of the microwave and the calculations of their electromagnetic fields in the near zone, which is very important when solving the problems of electromagnetic compatibility.

The book included the original material received by the authors. In particular, the method of physical regulatory (self -confined method) of the calculations of the electromagnetic field of antennas is described, which allows a continuous transition from the emitting surface of the antenna to the space outside it.

the textbook is intended for students of specialties: 210400 Radio Engineering and 210601 “Radio -Electronic systems and complexes. " Can be used by the developers of microwave equipment and antenna-feeder devices.
